Analog Output Module AQ4 6ES7532-5HD00-0AB0 SIMATIC S7-1500

Analog Output Module AQ4 SIMATIC S7-1500

The Siemens SIMATIC S7-1500 AQ 4xU/I ST (6ES7532-5HD00-0AB0) is a analog output module for the SIMATIC S7-1500 PLC and ET 200MP distributed I/O systems. The PLC into analog signals (voltage or current) to control field devices like variable speed drives, proportional valves, or servo motors.

Features and Technical Data:

• Outputs: This module has 4 analog outputs that can be configured for either voltage or current signals.
• Signal Ranges:
  • Voltage: 0 to 10 V, 1 to 5 V, and -10 to +10 V.
  • Current: 0 to 20 mA, 4 to 20 mA, and -20 to +20 mA.
• Resolution: It offers a high 16-bit resolution, which provides very fine control over the output signal. The accuracy is specified as 0.3%.
• Power: It operates on a 24 V DC power supply and has a typical power loss of 4 W.
• Physical Characteristics: It requires a separate front connector (available in screw or push-in versions) for wiring.
