Omron Module Pulse Output direction NX-PG0122

Omron Module Pulse Output NX-PG0122

The Omron NX-PG0122 is a 1-axis pulse output unit for the Omron NX I/O System. It’s a key component for applications requiring precise motion control, such as driving stepper motors and servo amplifiers with pulse and direction signals.

Key Specifications and Features:

• Function: Pulse Output Unit for motion control.
• Axes: 1-axis pulse output.
• Pulse Output Method: Supports both forward/reverse direction pulse outputs and pulse + direction outputs.
• Control: It provides a PNP open collector output type.
• Compatibility: The Omron NX-series I/O system. It works with a compatible CPU unit or EtherCAT Coupler Unit.
• Compact Design: The module has a very narrow width of 12 mm, which helps to save space in the control cabinet.

Product Status:

It is a current and essential component of the NX I/O series, which is part of Omron’s modern automation platform. It is widely available through official channels.
