Phoenix Contact Universally Configurable TC Temperature MINI MCR-2-T-2RO-PT

Phoenix Contact TC Temperature MINI MCR-2-T-2RO-PT

The Phoenix Contact Universally Configurable TC Temperature MINI MCR-2-T-2RO-PT, with item number 2906877. It features two transistor outputs and is designed for connecting 2, 3, and 4-conductor resistance thermometers (RTDs) and thermocouples (TCs).

Technical key features:

• Input: Accepts signals from various RTDs (Pt, Ni, Cu) and thermocouples (B, E, J, K, N, R, S, T, L, U, A-1, A-2, A-3, M, L). It has one input channel.
• Configuration: Can be configured via DIP switches directly on the device, free software solutions, or a smartphone app using NFC communication.
• Outputs: Two normally open (N/O) transistor outputs for switching based on configured temperature limits. Maximum switching voltage is 30 V DC, and the maximum switching current is 100 mA (at 30 V DC).
• Power Supply: Requires a nominal supply voltage of 24 V DC (range 9.6 V DC to 30 V DC).
• This device can be used for temperature monitoring and control in various industrial applications.
