Schneider Motion controller TSX3721001

Schneider Motion controller TSX3721001 & TSXAEZ802 (Input module), TSXDMZ64DTK (I/O Module), TSXDEZ12D2K Input Module of Schneider. The Schneider Electric (Telemecanique) TSX3721001 is a modular base controller from the Modicon TSX Micro automation platform.

While it is a Programmable Logic Controller (PLC) by design, it is frequently used as a motion controller in older systems by adding specialized counting and positioning modules.

Technical Specifications:

Feature	Specification
Primary Voltage	100–240V AC (Operating range: 90–264V AC)
Integrated Slots	3 slots for standard or half-format modules
Processor Speed	0.13 µs for Boolean instructions
Memory (Internal)	20 Kwords RAM (Data), 15 Kwords Flash (Backup)
Memory Expansion	Supports PCMCIA cards up to 128 Kwords
Communication	1 x RS485 (TER/AUX) Uni-Telway / Modbus RTU
Protection	IP30 (Indoor use only)
