The Schneider Electric VW3A1101 is a remote graphic display terminal (keypad) used for programming, controlling, and monitoring Altivar series Variable Speed Drives (VFDs).

Key features and programming use include:

• VFD Compatibility: It is compatible with a range of Altivar VFDs, including the Altivar 212, 312, 32, 61, 71, Altivar Lift, and Altivar Machine ATV320.
• Functionality:
  • Controlling, adjusting, and configuring the drive’s parameters.
  • Displaying current values (motor, input/output values, etc.).
  • Saving and downloading drive configurations
• Display: It features a high-resolution 240 x 160 pixel display with an 8-line message capacity.
• Programming Access: To fully utilize the keypad for programming, you may need to set the access level on the VFD

Summery:

You can learn how to efficiently transfer program parameters between two Altivar drives using this keypad. This video is relevant as it provides a tutorial on using the VW3A1101 graphical keypad to manage VFD programming and configurations.
