SEMIKRON SKIIP83AC12IT1 IGBT POWER MODULE

IGBT POWER MODULE

The SEMIKRON IGBT SKIIP83AC12IT1 is a highly integrated Power Module. The Semikron Key to Intelligent Power indicates it is an Intelligent Power Module (IPM) that combines an IGBT module with an integrated gate driver. This makes it an ideal building block for motor drives and other power conversion applications.

Key Specifications:

• Intelligent Power Module (IPM) with an integrated gate driver.
• This means it includes a three-phase input rectifier, a brake chopper, and a three-phase inverter, all in one module.
• Converter-Inverter-Brake (CIB) configuration. Voltage Rating: 1200V.
• Current Rating: 83A (some sources cite a nominal collector current of 50A for the inverter).
• Key Technology: MiniSKiiP package with solder-free spring contacts, which simplifies assembly, improves reliability against shock and vibration, and reduces parasitic inductance.
• Integrated Features: Includes a built-in NTC (Negative Temperature Coefficient) temperature sensor for monitoring and protection.
• Applications: Designed for a wide range of high-power electronic applications including:
• Variable Frequency Drives (VFDs) and AC Motor Drives
• Servo control systems
• Uninterruptible Power Supplies (UPS)
• Renewable energy systems (solar and wind inverters)
