Yaskawa JEPMC-MP2300S-E Motion Controller MP2300

Yaskawa JEPMC-MP2300S-E Motion Controller

The Yaskawa JEPMC-MP2300S-E is a dedicated Motion Controller that belongs to the MP2300 Series of controllers from Yaskawa. It is designed for high-performance, synchronized multi-axis motion control applications, forming the core logic unit in a Yaskawa motion system.

Technical Specification:

Feature	Specification / Detail
Product Type	Dedicated Motion Controller
Series	MP2300 (MP2000 Series)
Control System	Single CPU with Multi-Tasking OS
Control Language	Ladder Logic (IEC 61131-3) and Motion Programming (via Motion Basic or G-Code)
Motion Network	MECHATROLINK-II (Built-in)
Controlled Axes	Supports up to $32$ axes (via MECHATROLINK-II). The specific model may be limited to a lower number by license or performance tier.
Communication	Built-in Ethernet (for programming, HMI, and communication) and RS-232C
Programming Software	MP2000 or MP3000 software (MPE720 Engineering Tool)
High Speed	Highly deterministic control loops optimized for rapid execution and synchronization.
I/O	Base model includes some integrated digital I/O, but is usually expanded using MECHATROLINK I/O modules (e.g., JI-series).
