Panasonic MINAS A6S AC Servo Driver MDDLT55SF

Panasonic MINAS A6S AC Servo Driver MDDLT55SF

The Panasonic MINAS A6S Series AC Servo Driver MDDLT55SF is a high-performance servo drive designed for applications in industrial automation. The MINAS A6S indicates it’s part of Panasonic’s advanced A6 series

Technical Key Specifications and Features:

• Part Number: MDDLT55SF
• Series: MINAS A6S (A6SF Series)
• Rated Output Power: 1.5 kW (Kilowatt)
• Supply Voltage: Single-phase or 3-phase 200 V AC to 240 VAC
• Control Methods:
  • Position control
  • Velocity control
  • Torque control
  • Full-closed control
  • Switching among these modes is enabled.
• Encoder Feedback: Equipped with a 23-bit absolute encoder (8,388,608 resolution) using a 7-wire serial connection.
